Wathai 40mm x 20mm 12V Dual Ball Bearing DC Brushless Cooling Fan 2pin 4020
Bottom line: The Wathai 40mm x 20mm 12V Dual Ball Bearing DC Brushless Cooling Fan ($13.99 on Amazon as of 2026-11-20 11:19 UTC): 6000RPM pushes a rated 7.85CFM through a compact 40mm frame; main trade-off: 2-pin only: no tachometer signal or PWM speed control.
As an Amazon Associate, SpecPicks earns from qualifying purchases. Full disclosure →
*Price sourced from Amazon.com. Last updated 2026-11-20. Product prices and availability are accurate as of the date/time indicated and are subject to change. Any price and availability information displayed on Amazon.com at the time of purchase will apply to the purchase of this product.
Pros & Cons
Pros
- ✓ 6000RPM pushes a rated 7.85CFM through a compact 40mm frame
- ✓ Dual ball bearings rated for a 50,000-hour lifespan
- ✓ Low 0.05A draw at 12V, light load on small supply rails
- ✓ XH2.54 2-pin plug on a 20cm (8 in) lead for direct swaps
- ✓ Mounting screws and nuts included with the fan
Cons
- ✗ 2-pin only: no tachometer signal or PWM speed control
- ✗ 20mm depth won't fit slots built for slimmer 40x10mm fans
- ✗ 12V only; 5V or 24V boards need a different fan or a converter
- ✗ Sold as a single fan, so multi-fan swaps need extra units
Manufacturer description
The Wathai 4020 is a 40mm x 40mm x 20mm, 12V DC brushless cooling fan for replacing worn or noisy fans in compact electronics. You can fit it in PSUs, battery chargers, 3D printers, network switches, NAS enclosures and DVRs, which are all places where a 40mm fan has to move air through a tight space. At 12V the fan spins at 6000RPM, draws 0.05A and moves a rated 7.85CFM, with a listed noise level of 26dBA. Dual ball bearings carry a rated lifespan of 50,000 hours. That suits equipment that runs around the clock, like a NAS or DVR, where a sleeve-bearing fan tends to dry out and rattle. The…
SpecPicks Verdict
SpecPicks has no buyer-rating or benchmark data for Wathai 40mm x 20mm 12V Dual Ball Bearing DC Brushless Cooling Fan…, so this read rests on the manufacturer's listed specs and the current price in the power supplies category (how we evaluate). Compare with similarly-priced alternatives in the power supplies category before committing. On the listing's own facts, the case for it is "6000RPM pushes a rated 7.85CFM through a compact 40mm frame"; the main trade-off is "2-pin only: no tachometer signal or PWM speed control". If those two points fit how you will use it, put it beside one or two close alternatives in the Compare tool to confirm the price.
Common buyer scenarios for power supplies of this kind: matching it to an existing build, replacing a failing part, or upgrading from a previous-generation equivalent. Check the spec table below against your current setup — particularly socket / form-factor / power-rating fields — and confirm compatibility on the retailer's listing before purchase. Prices and stock are set by the retailer and may have moved since this page was last updated.
Frequently Asked Questions
Will this fan work on a 24V 3D printer?
Not directly. The Wathai 4020 is rated for 12V at 0.05A. On a 24V printer board you would need a step-down converter, or a 24V version of a 40x20mm fan.
What connector does the Wathai 4020 fan use?
It has a 2-pin XH2.54 connector on a 20cm (8 inch) cable. If your device uses a different plug, such as a 3-pin header or a JST-PH, you will need an adapter or to re-terminate the wires.
Is this fan the same size as a 4010 fan?
No. The frame is 40mm x 40mm like a 4010, but it is 20mm deep (0.79 in) instead of 10mm. Measure the available depth in your PSU, NAS or printer shroud before buying.
How loud and how strong is the airflow?
It is rated at 6000RPM, 7.85CFM of airflow and 26dBA of noise when running at 12V.
What comes in the box, and how long does the fan last?
You get one fan with mounting screws and nuts. The dual ball bearings are rated for a lifespan of 50,000 hours. Check the product listing for current warranty terms.
Key Features
Quoted from the manufacturer's listing. Where it differs from the pros and cons above, those note the conditions the listing leaves out.
- 40x20mm size fan for replacing fans in inverter and storage equipmentcs such as PSU,battery charger, 3D printer, switches, NAS , DVRs etc
- The 40mm DC brushless fan operates at 12V, ideal for cooling electronic equipment. This compact 40x40x20 12V fan ensures efficient cooling for various electronics, making it a reliable choice for 12V cooling needs
- Dual ball bearing providing reliable performance for prolonged periods with a lifespan of 50,000 hours
- Rated Voltage:12V 0.05A; Speed: 6000RPM; Air flow: 7.85CFM; Noise:26dBA; Connecter: XH2.54-2Pin; Cable Length: 20cm Or 8 inche
- 1 Piece fan and mounting screws & nuts; Dimension: 40mm(L) x 40mm(W) x 20mm(H) / 1.58x1.58x0.79 in. per fan
Full Specifications
| Brand | Wathai |
|---|---|
| Model | 4020B12V2P2.5 |
| Voltage | 12 volts_of_direct_current |
| Material | Plastic |
| Dimensions | 1.58x1.58x0.79 in |
| Unit Count | 1 Count |
| Noise Level | 26 db |
| Part Number | 4020B12V2P2.5 |
| Material Type | Plastic |
| Rated Voltage | 12V 0.05A; Speed: 6000RPM; Air flow: 7.85CFM; Noise:26dBA; Connecter: XH2.54-2Pin; Cable Length: 20cm Or 8 inche |
| Cooling Method | fan cooling |
| Number of Items | 1 |
| Number of Packs | 1 |
| Air Flow Capacity | 7.85 cfm |
| Compatible Devices | Amplifier, Desktop, Gaming Console, Printer, Projector |
| Power Connector Type | 2-Pin |
| Maximum Rotational Speed | 6000 rpm |
| Item Dimensions L x W x H | 1.56"L x 1.58"W x 0.79"H |
