24 Pin to 8 Pin ATX Power Supply Adapter Cable for DELL Optiplex PC Computers
daier

24 Pin to 8 Pin ATX Power Supply Adapter Cable for DELL Optiplex PC Computers

Bottom line: The daier 24 Pin to 8 Pin ATX Power Supply Adapter Cable: Converts a standard ATX 24-pin PSU plug to Dell's 8-pin board socket; main trade-off: only for Dell boards with the 8-pin main power socket.

Check price on Amazon

As an Amazon Associate, SpecPicks earns from qualifying purchases. Full disclosure →

Mike Perry — Hardware researcher since 2014. For retro PC hardware and period-correct parts, synthesises manufacturer documentation, community compatibility lists and marketplace listings rather than first-hand lab testing. Core beat: GPU performance across gaming, rendering, and local-LLM inference.

Pros & Cons

Pros

  • ✓ Converts a standard ATX 24-pin PSU plug to Dell's 8-pin board socket
  • ✓ Listed for Dell OptiPlex 3020, 7020, 9020 and T1700 motherboards
  • ✓ Also fits Dell H61/H81/Q77/Q87/B75/A75/Q75/Q65 8-pin boards
  • ✓ 18AWG wiring, rated by the maker for PSUs up to 1000W
  • ✓ Lets you reuse an OptiPlex board in a new case with a retail ATX PSU

Cons

  • ✗ Only for Dell boards with the 8-pin main power socket
  • ✗ Cable length is not stated in the listing
  • ✗ Wire colours may not match the product photos
  • ✗ Adds another connector joint to route inside the case

Manufacturer description

The daier 24 Pin to 8 Pin ATX power supply adapter cable lets you power a Dell OptiPlex motherboard from a standard ATX power supply. The Dell OptiPlex 3020, 7020 and 9020 and the T1700 boards use an 8-pin main power socket instead of the usual 24-pin ATX header, so a retail PSU won't plug into them directly. This adapter takes your PSU's 24-pin plug on its female end and gives you an 8-pin male connector that fits the Dell board. This helps if your original Dell power supply has failed, or if you're moving an OptiPlex board into a new case with a stronger PSU to support a graphics card…

SpecPicks Verdict

SpecPicks has no buyer-rating or benchmark data for daier 24 Pin to 8 Pin ATX Power Supply Adapter Cable, so this read rests on the manufacturer's listed specs (how we evaluate). Compare with similarly-priced alternatives in the power supplies & cables category before committing. On the listing's own facts, the case for it is "Converts a standard ATX 24-pin PSU plug to Dell's 8-pin board socket"; the main trade-off is "Only for Dell boards with the 8-pin main power socket". If those two points fit how you will use it, put it beside one or two close alternatives in the Compare tool to confirm the price.

Common buyer scenarios for power supplies & cables of this kind: matching it to an existing build, replacing a failing part, or upgrading from a previous-generation equivalent. Check the spec table below against your current setup — particularly socket / form-factor / power-rating fields — and confirm compatibility on the retailer's listing before purchase. Prices and stock are set by the retailer and may have moved since this page was last updated.

Frequently Asked Questions

Will this adapter work with my Dell OptiPlex 7020?

Yes. The listing names the OptiPlex 3020, 7020 and 9020 and the T1700 motherboards, which all use Dell's 8-pin main power socket.

Which connector goes to the power supply and which goes to the motherboard?

The 24-pin female end takes the main plug from a standard ATX power supply. The 8-pin male end plugs into the 8-pin power socket on the Dell motherboard.

What wire gauge does the cable use, and can it handle a high-wattage PSU?

It uses 18AWG wire, and daier says it supports power supplies up to 1000W.

Does it work with Dell boards other than OptiPlex?

The listing says it works with Dell H61, H81, Q77, Q87, B75, A75, Q75 and Q65 motherboards that use the 8-pin main power layout. Check that your board has an 8-pin main power socket before you buy.

Does this adapter also supply CPU, SATA or GPU power?

No. It converts only the main 24-pin connector to Dell's 8-pin socket. CPU, SATA and PCIe power must come from your power supply's own cables. For warranty terms, check the product listing.

Key Features

Quoted from the manufacturer's listing. Where it differs from the pros and cons above, those note the conditions the listing leaves out.

  • ATX 24Pin Female to for DELL Optiplex 3020 7020 9020 T1700 Server Motherboard 8Pin Male Adapter Power Cable.
  • DELL Optiplex 3020 7020 9020 T1700 Motherboard 8Pin Power.
  • 8Pin Compatible with for Dell H61/H81/Q77/Q87/B75/A75/Q75/Q65 etc motherboard.
  • 18AWG wire, support 1000W high power PSU.

Full Specifications

Branddaier
ColorBlack
Gauge18
ModelE806
Wattage1000 watts
Cable TypeATX Power Connector Cable
Item ShapeRound
Model NameOptiplex
Unit Count1 Count
Part NumberE806
CompatibilityPC
Connector TypeAtx
Number of Pins32
Maximum Current9.09 A
Maximum Voltage12 volts
Number of Items1
Special FeatureBraided
Connector GenderMale-to-Female
Compatible DevicesPC, Server
Indoor Outdoor UsageIndoor, Outdoor
